產品型號 | 輸出模式 | 工作電壓(V) | 工作溫度(°C) | 靈敏度(mV/A) | 隔離電壓(V) | 原邊阻抗(mΩ) | VOUT(V) | 量程 | 封裝 |
---|---|---|---|---|---|---|---|---|---|
CC6900 | 隨動增益 | 4.5~5.5 | -40~125 | 400~67 | 100VAC | 0.45 | 0.500~2.500~4.500 | ±5A, ±10A, ±20A, ±30A | SOP8 |
CC6902 | 隨動增益 | 4.5~5.5 | -40~125 | 400~67 | 2kVAC | 0.45 | 0.500~2.500~4.500 |
±5A,±5B,±10A, ±20A,±30A |
SOP8 |
CC6903 | 隨動增益 | 3~3.6 | -40~125 | 132~44 | 100VAC | 0.45 | 0.330~1.650~2.970 | ±10A, ±20A, ±30A | SOP8 |
CC6904 | 隨動增益 | 3~3.6 | -40~125 | 132~44 | 2kVAC | 0.45 | 0.330~1.650~2.970 | ±10A, ±20A, ±30A | SOP8 |
CC6905 | 固定增益 | 3~3.6/4.5~5.5 | -40~125 |
400~40/ 264~26.4 |
100VAC | 0.45 |
0.33~1.65~2.9/ 0.5~2.5~4.5,0.33~2.97/ 0.5~4.5/ |
±5A, ±10A, ±20A, ±30A,±40A,±50A, +5A,+10A,+20A, +30A,+40A,+50A |
SOP8,DFN8-3X3 |
CC6906 | 固定增益 | 3~3.6/4.5~5.5 | -40~125 |
10~6.67/ 13.2~4.4 |
100VAC | 0.03 |
0.500~2.500~4.500/ 0.33~1.65~2.97 |
±100,±150,±200, ±250,±300,±400 |
TO263-7 |
CC6907 | 隨動增益 | 4.5~5.5 | -40~125 | 200~30.75 | 3.75kVAC | 0.45 | 0.500~2.500~4.500 | +20A, +40A, +65A, +75A, | SOP16W |
CC6920 | 隨動增益 | 4.5~5.5 | -40~125 | 400~40 | 3.5kVAC | 0.9 | 0.500~2.500~4.500 |
±5, ±10, ±20, ±25, ±30, ±40, ±50 |
SOP8 |
CC6920B | 隨動增益 | 3~3.6 | -40~125 | 264~26.4 | 3.5kVAC | 0.9 | 0.330~1.650~2.970 |
±5, ±10, ±20, ±25, ±30, ±40, ±50 |
SOP8 |
CC6921 | 隨動增益 | 4.5~5.5 | -40~125 | 200~30.75 | 3.5kVAC | 0.45 | 0.500~2.500~4.500 |
±10, ±20, ±30, ±40, ±50,±65,±75, ±100 |
SOP16W |
CC6921B | 隨動增益 | 3~3.6 | -40~125 | 0.330~1.650~2.970 | 3.5kVAC | 0.45 | 0.500~2.500~4.500 |
±10, ±20, ±30, ±40, ±50,±65, ±75, ±100 |
SOP16W |
CC6922 | 固定增益 | 3~3.6/4.5~5.5 | -40~125 |
100~20/ 66~13.2 |
5kVAC | 0.3 |
0.500~2.500~4.500/ 0.33~1.65~2.97 |
±20, ±30, ±40, ±50,± 65,±75, ±100 |
SOP16W |
CC6923 | 隨動增益 | 3~3.6/4.5~5.5 | -40~125 |
100~20/ 66~13.2 |
5kVAC | 0.3 |
0.500~2.500~4.500/ 0.33~1.65~2.97 |
±20, ±30, ±40, ±50,± 65,±75, ±100 |
SOP16W |
CC6924 | 固定/隨動增益 | 3~3.6/4.5~5.5 | -40~125 |
100~20/ 66~13.2 |
5kVAC | 0.3 |
0.500~2.500~4.500/ 0.33~1.65~2.97 |
±20, ±30, ±40, ±50,± 65,±75, ±100,±125,±150 |
SOP16W |
CC6925 | 固定/隨動增益 | 3~3.6/4.5~5.5 | -40~125 |
1.6~16 ~29/ 2.4~24~44 |
/ | / |
0.500~2.500~4.500/ 0.33~1.65~2.97 |
±200 ~±1000 | DFN8 4×4 |
CC6926 | 固定增益 | 3~3.6/4.5~5.5 | -40~125 |
10~6.67/ 13.2~4.4 |
5kVAC | 0.03 |
0.500~2.500~4.500/ 0.33~1.65~2.97 |
±100,±150,±200, ±250,±300,±400 |
TO263-7 |
CC6927 | 隨動增益 | 4.5~5.5 | -40~125 |
40~10/ 26.4~6.6 |
100VAC | 0.3 |
0.500~2.500~4.500/ 0.33~1.65~2.97 |
±50,±100,±150,±200 | DFN6.4×6.4 |
CC6928 | 固定/隨動增益 | 3~3.6/4.5~5.5 | -40~125 |
100~20/ 66~13.2 |
5kVAC | 0.3 |
0.500~2.500~4.500/ 0.33~1.65~2.97 |
±20, ±30, ±40, ±50,± 65,±75, ±100 |
SOP16W |
